Joranalogue Cycle 5

Eurorack Analog VCO

• Compact 6 HP oscillator with high-stability triangle-core core
• 7-octave switch and perfect fifth transposition for instant intonation
• Dual 1V/Oct inputs for complex sequences and exponential FM
• Multiple outputs: sine, triangle, sawtooth, square/pulse and vari-wave
• CV-controllable vari-wave function for continuous morphing between waveforms
• LFO mode, hard sync and wide frequency range
• Designed and manufactured in Belgium with high-quality components

Compact and musical analog oscillator

The Joranalogue Cycle 5 is a triangle-core analog VCO designed to offer precision, musicality and versatility in only 6 HP. Thanks to factory calibration and the presence of a 7-octave switch plus one dedicated to the perfect fifth, tuning becomes immediate: just center the fine tuning to be immediately on reference C.

Classic Waveforms and Vari-Wave Function

In addition to the classic sine, triangle, sawtooth and square/pulse (PWM) waveform outputs, Cycle 5 introduces the Vari-Wave output with continuous morphing controllable via CV: from sine to narrow pulse, through all waveforms in between. A powerful feature for both intense timbres and smooth modulations.

Precision, connectivity and intelligent design

Dual volts per octave input allows complex configurations such as sequences + FM or dynamic transpositions. The module also includes an LFO mode, hard sync input, front-panel accessible potentiometers and two-tone LED indicators.

Technical Specifications.

• Type: high-stability triangle-core analog VCO
• Size: 6 HP
• Power consumption: +12 V: 75 mA, -12 V: 70 mA
• Frequency range: 48 mHz (20 s) to 3.7 kHz
• Outputs: sine, triangle, saw, square/pulse, vari-wave
• Inputs: 2x 1V/Oct, hard sync, CV vari-wave
• 2 mm anodized aluminum panel, precision milled
• MOSFET protection circuit and polarized connector
• Includes flat cable, black screws, washers and hex key
• Made in Belgium
