API Select T12 Tube Mic Preamp
Class A 2-channel tube microphone preamp
- All-tube, Class-A microphone preamplifier
- Proprietary AP2516 input transformer
- Audio circuit uses 12AT7WC and 12BH7, dual-triode vacuum tubes
- Custom API output transformer
- Variable microphone input impedance
- Switchable 48-volt phantom power
- High-impedance, unbalanced 1/4" instrument input
- MIC/HI-Z input switch
- -20dB input pad
- 11-step detented preamp gain control
- Low-cut filter with 3 fixed frequencies
- 11-step detented output trim with 0.5dB steps for precise control
- Detented controls for accurate recall and channel matching
- LED peak indicator
- Classic analog VU meters for output
- XLR and 1/4" TRS output connections
API Select T12 Tube Mic Preamp
Preamplificatore microfonico a 2 canali valvolare in classe A
L'API Select T12 è un classico preamplificatore microfonico di Classe A a 2 canali, interamente valvolare, progettato con il trasformatore AP2516 proprietario di API nello stadio di ingresso e un trasformatore API personalizzato sullo stadio di uscita. Costruito con tubi a vuoto a doppio triodo 12AT7WC e 12BH7, il T12 rappresenta una nuova ed entusiasmante variazione nella tecnologia del preamplificatore API e offre all'utente opzioni tonali uniche. Il T12 può gestire un'ampia gamma di applicazioni di produzione, incluso il funzionamento stereo. Progettato con cura per offrire prestazioni e suono valvolari classici, il T12 offre il famoso calore, punch e chiarezza di API in un modo completamente nuovo e presenta la nostra garanzia di cinque anni esclusiva del settore.Specifiche Tecniche
| Input Impedance: | • Microphone: 500Ω, 1500Ω, 2000Ω, & 2500Ω (variable) • HI-Z: 500kΩ |
| Output Impedance: | 75 ohms, can drive 600 ohm loads |
| Maximum Input Level: | +24dBu with -20dB PAD engaged and gain set to 20dB |
| Gain Range: | 0dB to +70dB |
| Maximum Output Level: | +24dBu |
| SNR: | 98dB |
| Frequency Response: | 20Hz – 30kHz (+0dB / -1dB) |
| Power Consumption: | 40W |
| Size: | 19" x 3.5" x 12" Deep |
| Size (Boxed for Shipping): | 21" x 9" x 15" |
| Actual Weight: | 14 lbs. |
| Shipping Weight: | 17 lbs. |
ADC
No
Channels
2 (Stereo)
Hardware format
Rack
€ 2.172,13 Ex VAT
For European customers, select your country to view the correct price including VAT.
