Sistema Sommatore analogico e Control Room Compatto
Perfect for the Modern Workflow and Compact Environment of the Mobile and Small-Footprint DAW Studio Setup
– Analog Summing
– Monitor Control
– On-board D/A conversion
– Talkback
– Headphone Cue
– Simultaneous Input Monitoring
More and more records are being tracked and mixed in remote or temporary locations with mobile DAW rigs. Control room setups can be tight. A reliable and flexible audio environment is a must. No need to sacrifice mix quality or struggle with monitor control! For integrated monitoring, mixing, and input selection for the computer musician on the go, the Dangerous D-Box is the uncompromising and affordable solution for all DAW-based musicians and engineers who need to trust what they hear.
– Unmatched Analog Summing Section
– Superb Onboard D/A Converter
– 2 Speaker Outputs
– Affordable for all DAW studio owners
SUMMING SECTION:8 input dedicated fixed-gain analog summing buss
Master output trim with 10 dB range
Inputs 7-8 with pan control
Signal present indicators for all inputs
MONITOR SECTION:Analog and digital capable input selector designed specifically to facilitate the analog summing workflow
Programmable exclusive/additive function- listen to selected inputs individually or combined
High-quality onboard D/A conversion 2 digital inputs – AES or PDIF 32kHZ – 100kHz sample rate
Auxiliary stereo analog input- +4 dBU or – 10 dBV programmable
2 sets of speaker outputs
Mono function
CUE/TALKBACK SECTION:
Built-in talkback microphone with “momentoggle” switching
2 headphone outputs with independent level controls
Auxiliary talkback switch input
Specifications
Frequency Response: 1 Hz-100 kHz within 0.1 dB
Total Harmonic Distortion: 0.003% in audio band
Intermodulation Distortion: 0.005% IMD60:4
Crosstalk @ 1 kHz: -97 dB
Noise floor: -88 dBu total energy in audio band
Max level: +26 dBu
Nominal operating level: +4 dBu
D/A Converter- locks to standard AES or PDIF signals 32kHz-100kHz sample rate
D/A Crosstalk: -100 dB
Input impedance: 25K ohm balanced
Output impedance: 50 ohms balanced (600 ohm drive capable)
Power consumption: 25 watts
