SPL MMC2

SPL MMC2

Console di mastering multicanale con tecnologia 120V

The purely analog designed MMC2 Multichannel Mastering Console achieves the highest possible audio performance with our unrivaled 120V Technology.

As the centerpiece in Multichannel Mastering environments the MMC2 manages all tasks such as source-, insert-, master- and monitor-operations with ease.

• Eight-Channel Mastering Console
• 120V DC Audio Rail – SUPRA Op-Amps
• 2 Stereo Inputs and 4 Stereo Return Sources
• 2 Eight-Channel Inputs and 2 Eight-Channel Return Sources
• 4 Stereo Recording Outputs
• 2 Eight-Channel Recording Outputs
• 2 Stereo Monitor Outputs
• 2 Eight-Channel Monitoring Outputs
• Input Trim +/- 10 dB with eight 41 steps trimmer
• Output Trim +/- 10 dB with eight 41 steps trimmer
• Insert/Return Routing for external processors
• Eight-Channel Master Recording Level Fader
• Eight-Channel Monitor Level Fader
• Comprehensive Speaker Management

Specifiche Tecniche

Dynamic Range > 130 dB

Inputs

• Max. input level: > 30 dBu
• Input impedance: 20 kOhms (bal.)

Outputs

• Output impedance: < 75 Ohms (bal.)
• THD & Noise (+24dBu):
  Recording Out: > 110 dBu
  Monitor Out: > 108 dBu
  Send: > 110 dBu

Power consumption:

• 1 Amp, 230V/50Hz
• 1.6 Amp, 115V/60Hz

Dimensions & Weight

• Width x Height x Depth (inch): 20.3 x 19 x 20.5 (516 x 482 x 520mm)
• Housing (19 inch, 11HE)
• Weight: 35kg
