- Dual-path 285-volt Class-A tube and transimpedance solid-state preamps
- Phase-aligned tone-blending of tube and solid state circuits, creamy to crunchy
- Newly designed 1176-style compression circuit per preamp channel
- JFET Direct Input with 2.2MΩ ultra Hi-Z impedance w/auto input override
- Large backlit VU meters for flexible metering of input drive, gain level, and gain reduction
- Balanced send/return inserts (half-normalled)
- 48V phantom power
- 75 Hz low cut filter
- Polarity switch
- Monolithic balanced output stage
- Eight channels of high quality 24-bit A/D conversion
- Selectable sample rates up to 192 kHz
- Digital output via dual ADAT optical and AES/EBU DB-25 connectors
- 8-channel soft limiter (switchable for all channels)
- Ultra-low jitter clock subsystem
- 75Ω BNC work clock I/O
Universal Audio 4-710d (usato)
Mic Pre 4 canali con dinamica e converitori A/D
Il
4-710D è un preamplificatore microfonico e DI “Twin-finity” con Dinamica a Quattro Canali.
Il suo nucleo centrale sono quattro canali di pre-amplificazione microfonica “Twin-finity” tone-blending ed una compressione true-bypass in perfetto stile 1176. Basato sull’originalissimo e pluri-premiato preamplificatore 710 Twin-Finity. Ognuno dei quattro canali di preamplificazione microfonica consente di miscelare in modo continuo tra il 100% della sonorità valvolare ed il 100% di quella solid-state. Un circuito di compressione/soft-limiting completamente ri-progettato in perfetto stile 1176 per ogni canale microfonico Otto canali di conversione A/D di altissima qualità a 24-Bit, 192kHz
Uscite digitali ottiche dual ADAT o AES/EBU su DB-25 Stadio di uscita solidamente bilanciato (Monolithic Balanced) Inserti send/return bilanciati.
Specifiche Tecniche
Preamplifiers
Four TEC Award-winning 710 Twin-Finity™ microphone/line preamps, each featuring:
- Dual-path 285-volt Class-A tube and transimpedance solid-state preamps
- Phase-aligned tone-blending of tube and solid state circuits, creamy to crunchy
- Newly designed 1176-style compression circuit per preamp channel
- JFET Direct Input with 2.2MΩ ultra Hi-Z impedance w/auto input override
- Large backlit VU meters for flexible metering of input drive, gain level, and gain reduction
- Balanced send/return inserts (half-normalled)
- 48V phantom power
- 75 Hz low cut filter
- Polarity switch
- Monolithic balanced output stage
Analog-to-Digital Conversion
Eight channels of high quality 24-bit A/D conversion:
- Selectable sample rates up to 192 kHz
- Digital output via dual ADAT optical and AES/EBU DB-25 connectors
- 8-channel soft limiter (switchable for all channels)
- Ultra-low jitter clock subsystem
- LED metering array with clip/hold indicators
- 75Ω BNC work clock I/O
- Digital outputs anti-pop protection on power-up
Other
- Universal voltage internal power supply
- Heavy-duty metal construction, two-space rack unit
- One year warranty including parts and labor
