Avid Pro Tools | MTRX Studio

Dante and HDX audio interface 16 analog inputs 16 analog outputs - DSP for Dolby Atmos

• All-in-one audio interface with advanced routing and built-in monitoring
• Compatibility with Pro Tools | HDX and HD Native
• Full support for Dolby Atmos mixes up to 7.1.4
• Dante, DigiLink and ADAT connectivity
• High-quality audio with Digital Audio Denmark technology
• Low-latency monitoring and SPQ environmental calibration
• Remote control via EUCON with Avid surfaces

Pro Tools | MTRX Studio: the heart of your professional studio

Pro Tools | MTRX Studio is the ideal audio interface for professional studios seeking flexibility, total integration and superior sound quality. With advanced I/O, monitoring and routing capabilities, it allows you to centralize your audio flow and optimize every stage of your creative work. All this in a compact and powerful 1U rack unit.

Extensive connectivity for every need

Analog and digital inputs and outputs

With 16 analog inputs and 16 analog outputs on DB25, 64 Dante channels, 16x16 ADAT and dual DigiLink Mini connectors, you can connect microphones, monitors, outboards and other devices with extreme flexibility.

Unlimited audio routing

The 512 x 512 matrix managed by DADman allows custom routing from any input to any output, with cue mixes on Dante and signal management between different formats.

DAD audio quality and advanced monitoring

Precision converters and preamps

Made in collaboration with Digital Audio Denmark, MTRX Studio provides crystal-clear audio conversion and top-notch preamps for detailed vocal and instrumental recordings.

Sound monitoring and control

No need for an external controller: manage monitors, downmixes and profiles directly through DADman software, with seamless integration on Avid surfaces via EUCON.

Immersive mixing with Dolby Atmos support.

MTRX Studio is optimized for Dolby Atmos sessions up to 7.1.4 configurations, with detailed level control, built-in speaker calibration and delay management. Ideal for creating immersive mix environments in any space.

Remote control and optimized workflow

Control sources, monitors and routing directly from Pro Tools | Ultimate with native EUCON integration. Eliminate manual patching and minimize interruptions to your creative workflow.

Technical Specifications.

• Mic/Instrument inputs: 2 x 1/4″
• Analog Line I/O: 16 x 16 DB25
• ADAT I/O: 16 x 16
• Dante I/O: 64 x 64
• DigiLink I/O: 2 x Mini DigiLink (64 channels total)
• Dedicated monitor outputs: 2 x 1/4″
• Headphone outputs: 2 x 1/4″
• Digital matrix: 512 x 512
• Summing matrix: 256 x 16 with monitor profiles, fold downs, group formats
• Speaker calibration: 256 SPQ filters on 16 channels, delay up to 150 ms
• EUCON Integration: Yes
• Sync: Word Clock, Loop Sync (BNC), Dante Sync
• Supported frequencies: 44.1 kHz - 192 kHz
• Power Supply: Single
• Chassis: 1U, 19" rack mount
