RME MADIface XT II

MADI/USB3 professional audio interface

• Up to 394 audio channels via USB 3.0
• 2 XLR microphone inputs and 2 balanced line in/outs
• Dual optical MADI + coaxial MADI, AES, Word Clock
• TotalMix FX with Room EQ, Reverb, Delay and remote control
• SteadyClock FS for minimal jitter and precision clocking

RME MADIface XT II: compact interface, extreme power

RME MADIface XT II is a professional USB 3.0 audio interface with 394 channels at 192 kHz, ideal for live, studio and immersive production. An evolution of the legendary MADIface XT, this new version boasts upgraded analog and digital circuitry, superior audio performance and comprehensive connectivity in a compact desktop format.

Advanced MADI and analog connectivity

The MADIface XT II offers 2 combo mic/line inputs with preamp, 2 balanced XLR outputs, headphone output, dual optical MADI, coaxial MADI, AES/EBU, Word Clock and 4 MIDI ports. Perfect for complex multichannel setups and compatible with ARC USB for remote control.

Ultra Precise Clocking with SteadyClock FS

With SteadyClock FS technology, the interface ensures extremely low jitter and femtosecond-based digital reference clocking for exceptional audio quality even in critical environments.

TotalMix FX and Room EQ: limitless mixing and control

TotalMix FX turns the MADIface XT II into a powerful DSP mixer with advanced routing, monitor mix, 9-band parametric EQ, dynamics, reverb, delay and Room EQ for immersive setups. Control is possible via iPad, PC/Mac or via optional USB ARC remote control.

Class Compliant USB 3.0 mode

Native support for Windows, macOS and Linux without additional drivers. All 394 channels can be managed in Class Compliant mode, ensuring maximum compatibility and ease of use in any modern operating system.

RME reliability for every application

Perfect for studios, location recording, Dolby Atmos® environments, live and broadcast installations, MADIface XT II stands out for stability, low latency, versatility and constant software updates thanks to the proprietary RME core driver.

Technical Specifications.

• 394 I/O channels over USB 3.0 at 192 kHz
• 2 x Mic/Line XLR combo In, 2 x balanced XLR Out
• 1 x Headphone Out, 1 x AES/EBU, 1 x Word Clock I/O
• 2 x MADI optical, 1 x MADI coaxial
• 4 x MIDI I/O, USB ARC support
• TotalMix FX with Room EQ, Reverb, Delay
• SteadyClock FS, TotalMix Remote Control
• Class Compliant USB 3.0 Compatibility
• MacOS, Windows and Linux support
• Compact desktop format
