Elysia xfilter

Name: Elysia xfilter
Brand: Elysia
Price: 1040.16 EUR

Stereo equalizer with true link

SKU: 23872

Elysia xfilter

Stereo equalizer with true link

Link Me Up

The xfilter is a true linked stereo equalizer with the heart and soul of our flagship EQ, the museq. It gives you the expensive sound of an all class-A equalizer in a surprisingly affordable package, with a precise stereo image based on computer-selected, stepped pots and low tolerance film caps.

Massage Needed?

The xfilter is absolutely serious about flexibility. It offers high and low shelf bands which can be switched into high and low cut filters with resonance, two mid peak filters with wide and narrow Q, plus additional passive LC stages with shielded coils for a glorious top end. With its exceptionally open sound, straight transient projection and solid punch, the xfilter is the perfect match for your xpressor – or any other piece of delicious outboard gear!

Specifications

Frequency response <10 Hz - 400 kHz (-3.0 dB) THD+N @ 0 dBu, 20 Hz - 22 kHz: 0.0018 % @ +10 dBu, 20 Hz - 22 kHz: 0.005 % Noise floor 20 Hz - 20 kHz (A-weighted): -98 dBu Dynamic range 20 Hz - 22 kHz: 120 dB Maximum level Input: +21 dBu Output: +21 dBu Impedance Input: 10 kOhm Output: 68 Ohm
