Erica Synths Black Mute Mixer

Mixer with mute switch on each input and 3 buffered outputs

Erica Synths Black Mute Mixer is a compact, high quality audio mixer with bonus features – mute switch on each input and three buffered outputs.

Features

  • 3 AC coupled inputs
  • Mute switch on each input
  • 3 buffered outputs
  • Input and output protection
  • Protection against reverse PSU connection
This mixer allows you to add audio signals to your mix instantly and exactly in the right level, plus you can send signals to several post-mixer devices simultaneously, for example, split the output signal to LP and HP VCFs and create advanced bandpass and notch filters. Erica Black series are high-end modules with unique functionality. Only the highest quality components are used and all inputs and outputs are protected against undesired overvoltage. When designing the Black Series, we did not economise on the module width, we put design and usability first. Big knobs are assigned to functions that make difference in sound. Together the Erica Black series are a range of modules that make an entire synthesizer. Technical specifications:
Max input signal level -10V – +10V
Mixer gain 1
Power consumption +8mA, -8mA
Module width 6HP
Module depth 25mm

Depth

25 mm

Width

6 hp
