Adamsynths Multiples 16

Name: Adamsynths Multiples 16
Brand: Adamsynths
Price: 65.00 EUR

4-in, 12-out passive CV gate trigger multiplexer, Total Recall-compatible

SKU: 148415

Passive 4-in, 12-out CV gate trigger splitter, Total Recall compatible

Passive signal distributor with 4 inputs and 12 outputs
Intelligent priority routing: outputs are automatically routed based on the connected inputs
A single connected input distributes the signal to all 12 outputs
Fully passive operation, no power required
Ideal for distributing CV, gate, trigger, and audio signals
Fully compatible with cable detection and Total Recall in the Warthog system
Eurorack format, 4HP wide

The Adamsynths Multiples 16 is a passive signal distributor with 4 inputs and 12 outputs that dynamically adapts to your patching. It’s not just a simple signal distributor: the inputs follow a priority logic and automatically assign themselves to their respective output groups based on how many you connect. Completely passive and fully compatible with the Warthog system’s Total Recall, it allows you to route a single source to multiple destinations while preserving the signal integrity and precision of patch recall.

Priority Routing: The Passive Multiplexer That Adapts to Your Patching

The behavior of the Multiples 16 changes depending on which inputs are used, with no switches or menus to configure:

with only the first input connected, the signal is distributed to all 12 outputs;
with the first and second inputs active, the first feeds outputs 1 through 3 and the second feeds outputs 4 through 12;
with three inputs, the outputs are divided into groups of 3, 3, and 6;
with four inputs, the outputs are divided into four groups of 3.

One module, multiple distribution configurations

In practice, you can use it as a single large 1-to-12 distributor—for example, to send a clock signal or a note to the entire system—or as multiple independent distributors side by side, to simultaneously manage gates, pitch CV, and various modulations. The module adapts to your patching logic, with no configurations to memorize.

Passive distribution of CV, gate, trigger, and audio

The Multiples 16 operates completely passively and requires no power supply. You can use it to distribute control voltages, gates, triggers, and audio signals, expanding your system’s capabilities without drawing power and in just 4HP of rack space.

4HP Eurorack format

The Eurorack format makes it usable in both the Warthog system and any other modular setup, where it provides the same priority-based routing in a minimal footprint.

Compatibility with the Adamsynths Warthog System’s Total Recall

Adamsynths Warthog modules fully support passive distributors such as the Multiples 16. You can connect a single output to multiple inputs without degrading the signal while detecting cable positions or recalling patches: the system accurately tracks cable positions, ensuring Total Recall functions correctly.

Why Choose a Passive Splitter with Warthog

Active splitters are not recommended with the Warthog, as they can interfere with cable position detection and cause incorrect recalls. The Multiples 16 is therefore the ideal choice for expanding your system while preserving signal integrity and recall reliability.

Technical Specifications
