Audient iD14

• 10-in/4-out USB Audio Interface
• 2 x Class-A Audient Console Mic Preamplifiers
• High Performance Burr Brown AD/DA Converters
• iD ScrollControl Mode
• 1 x Discrete JFET Instrument Input
• Main Speaker Output
• Independent Class-AB Headphone Output
• Full Monitor Control Functionality (software controlled)
• ADAT Input for Expandability
• Low Latency DSP Mixer
• USB2.0 Bus Powered
• 24bit/96khz
• All-Metal Enclosure
• Free plugins and software with ARC

Audient iD14

Interfaccia Audio 10 in / 4 out

iD14 delivers the audio performance of a large format console in a compact and elegant desktop package. iD14 provides two Audient console mic pres, class-leading Burr Brown converter technology, console style monitor control, JFET D.I and our virtual scroll wheel technology, ScrollControl. With its versatile feature set and intuitive layout, iD14 will become the hub of your studio in no time.

Audient Console Mic Pres

The professional sound you deserve We are the only company that use the same Class-A mic pre design throughout our entire product range, whether you’re in the studio with an Audient console or on the road with iD14, you’re always guaranteed the same world class Audient sound.

Pristine Converter Technology

Brilliance on the inside enables brilliance on the outside iD14 provides you with high performance AD-DA converters. Quality in the analogue stages of design comes from years of experience as analogue console designers, and when coupled with outstanding converter technology it enables you to hear audio as it’s supposed to sound. The importance of converters should never be underestimated. Experience audio the Audient way.

Plug and Play

Simply plug in and be inspired As well as offering you 2 channels of mic pre, iD14 has a harmonically rich JFET D.I input. Designed to replicate the input stage of a classic valve amplifier, you can plug your guitar, bass, keyboard or drum machine straight in and start recording instantly.

ScrollControl

The virtual scroll wheel Get hands on control of your software with iD14’s ScrollControl. With a touch of a button iD14’s volume encoder becomes a virtual scroll wheel that allows you to adjust DAW hosts, plug-in parameters, iD14’s mixer app and even scroll through your iTunes library - just like you’re adjusting a piece of hardware. Wherever your mouse pointer hovers, the iD knob can scroll to control!

Expand

Grows with your needs Need to track drums? No problem! As your system grows, iD14 can be expanded via the optical input connector, supporting both ADAT or S/PDIF. Enabling you to expand up to ten inputs via an eight-channel mic pre, such as the ASP800.

Console Style Monitor Control

Customise your control surface When not using the virtual scroll wheel, the iD button can be assigned to control iD14’s monitoring features. Following in the footsteps of it’s critically acclaimed big brother iD22, we’ve still included DIM, CUT, Polarity Reverse, Mono Sum, Talkback and Cue Mix monitoring, all of which can be assigned to the iD button.

Intuitive software

Software you can rely on We understand the need to keep things simple and iD14’s mixer app was designed with that in mind. Whether you’re creating low latency cue mixes or utilising the flexible monitor control, iD14 tightly integrates the hardware and software making the recording process easy. Enabling you to concentrate on what’s really important - the music.

Built to last

Quality deserves protection iD14 has been designed to last, from its all-metal construction, hand finished aluminium knobs and high grade component selection, iD14 will stand up to countless late nights in the studio and days on the road.

---

Specifiche Tecniche

MICROPHONE PREAMPLIFIER:

(measurement includes ADC signal path)

MIC GAIN:	0 to 66 dB (inc. +10 dB software boost)
LINE GAIN:	-10 to 56 dB (-10dB hardwired line pad)
PHANTOM POWER:	48V ±4V @ 10mA/Channel (12VDC only)*
MIC EIN:	<-127.0 dBu
CMRR:	>80 dB @ 1kHz
MAXIMUM INPUT LEVEL:	+12 dBu (0 dBFS digital Maximum)
INPUT IMPEDANCE (Mic):	2.8 kΩ Balanced
INPUT IMPEDANCE (Line):	>8kΩ Balanced
FREQUENCY RESPONSE:	±0.1 dB 20Hz to 22kHz @ min. gain ±1.0 dB 20Hz to 22kHz @ max. gain
CROSSTALK:	<-90 dBu
THD+N @ 0dBu (1kHz):	0.0025% (-92 dBu)
SNR:	96 dB un-weighted, 99 dB A-weighted
XLR Combi Female	Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
1/4" TRS Jack	Tip (Hot), Ring (Cold) & Sleeve (Shield)

D.I (Channel 1):

D.I GAIN:	0 to 66 dB (inc. +10 dB software boost)
MAXIMUM INPUT LEVEL:	+9 dBu (0.6% THD typical)
INPUT IMPEDANCE:	>500kΩ Unbalanced
FREQUENCY RESPONSE:	±0.1 dB 20Hz to 22kHz
THD+N @ 0dBu (1kHz):	<0.04% all musical 2nd and 3rd harmonics
SNR:	95 dB un-weighted, 98 dB A-weighted
1/4” JACK:	TIP (Hot) & SLEEVE (Shield)

ANALOGUE TO DIGITAL CONVERTER (ADC 1 & 2):

(measured sans microphone preamplifier under AES-17)

MAXIMUM INPUT LEVEL:	+12 dBu (0 dBFS digital maximum)
DIGITAL REFERENCE LEVEL:	+12 dBu = 0 dBFS
FREQUENCY RESPONSE:	±0.1 dB 10Hz to Fs/2 (flat to nyquist)
CROSSTALK:	-100 dBu @ 1kHz & 10kHz
THD+N @ -1dBFS (1kHz):	<0.002% (-94 dB)
THD+N @ -6dBFS (1kHz):	<0.0015% (-97 dB)
DYNAMIC RANGE:	113 dB un-weighted 116 dB A-weighted

DIGITAL TO ANALOGUE CONVERTER (DAC 1&2):

(measured under AES-17 at line outputs 1&2)

MAXIMUM OUTPUT LEVEL:	+12 dBu (0 dBFS digital maximum)
DIGITAL REFERENCE LEVEL:	+12 dBu = 0 dBFS
OUTPUT IMPEDANCE	<100Ω Balanced
FREQUENCY RESPONSE:	±0.1 dB 10Hz to Fs/2 (flat to nyquist)
CROSSTALK:	<-105 dBu @ 1kHz & 10kHz
THD+N @ -1dBFS (1kHz):	<0.003% (-90.5 dB)
DYNAMIC RANGE:	114 dB un-weighted 117 dB A-weighted
1/4" TRS Jack	Tip (Hot), Ring (Cold) & Sleeve (Shield)

HEADPHONE OUTPUT (DAC 3&4):

(measured under AES-17 at phones output)

MAXIMUM OUTPUT LEVEL:	+12 dBu
DIGITAL REFERENCE LEVEL:	+12 dBu = 0 dBFS
VOLTAGE GAIN:	+6 dB (optimised for loudness)
OUTPUT IMPEDANCE:	<30 Ω Balanced
FREQUENCY RESPONSE:	±1.0 dB 10Hz to Fs/2 (load dependant)
CROSSTALK:	-100 dBu @ 1kHz & 10kHz
THD+N @ -1dBFS (1kHz):	<0.002% (-94 dB)
DYNAMIC RANGE:	108 dB un-weighted 111 dB A-weighted
MAX LEVEL INTO 30ohms:	+4 dBu, 0.005% THD+N, Power: 101mW
MAX LEVEL INTO 60ohms:	+5 dBu, 0.004% THD+N, Power: 64mW
MAX LEVEL INTO 600ohms:	+13 dBu, 0.0025% THD+N, Power: 39mW
1/4” JACK:	TIP (Left), RING (Right) & SLEEVE (Shield)

DIGITAL INPUT:

8-CHANNEL ADAT:	44.1kHz to 48kHz
4-CHANNEL ADAT:	88.2kHz to 96kHz SMUX
STEREO S/PDIF / TOSLINK	44.1kHz to 96kHz (Stereo)

USB 2.0 HIGH SPEED:

BUS POWER:	500mA @5V System Limit 425mA @5V Maximum (No 48V) (Phantom power only available on 12VDC)*
No. of INPUT CHANNELS:	10 (2 Analogue, 8 Digital)
No. of OUTPUT CHANNELS:	4 (4 Analogue)
DSP MIXER LATENCY:	ROUND TRIP (in-to-out) 44.1kHz 1.660ms 48.0kHz 1.531ms 88.2kHz 0.844ms 96.0kHz 0.771ms

DAW Roundtrip Software Monitoring Latency @ 32 Sample Buffer (in to out):

44.1 kHz	6.52ms
96.0 kHz	4.65ms

POWER SUPPLY:

12VDC Centre Positive - 1.25A (required for full 48V Phantom Power)* * iD14 requires a lot of power for class leading converters and class-A microphone preamplfiers. We could not beat the laws of physics so an external supply is required for 48V phantom power. Your microphones will thank you when they get enough voltage!
